    Infrared PTZ Thermal Imaging Camera 6KM , Long Range UFPA Sensor Camera

    Ask Lasest Price
    Brand Name : Hope-Wish
    Model Number : TC4307
    Certification : CE,FCC
    Payment Terms : L/C, T/T, Western Union
    Price : Negotiable
    • Product Details
    • Company Profile

    Infrared PTZ Thermal Imaging Camera 6KM , Long Range UFPA Sensor Camera

    6KM Long Range Infrared PTZ Thermal Imaging Camera for Border Security


    Feature:

    1. based on the latest uncooled IR sensitive technology and continuously IR optical zoom.
    2. User could get a best imaging details with 336*256/640*512 resolution uncooled FPA sensor, advanced digital circuit and image processing algorithm.
    3. Special design of 5X optical zooming lens have detection distance 16km, suit for both seeking and watching.
    4. One integral aluminum alloy housing make sure the camera works well outdoor.

    Technical specification

    ModelTC4307-STC4510-STC4412-STC4515-STC4519-S
    DetectionVehicle:6500mVehicle:8600mVehicle:10000mVehicle: 13000mVehicle: 16400m
    Human:2500mHuman:3400mHuman:4000mHuman: 4800mHuman: 5800m
    IdentificationVehicle:1800mVehicle:2400mVehicle:2800mVehicle:3400mVehicle:4200m
    Human:700mHuman:900mHuman:10000mHuman:1300mHuman: 1600m
    Sensor5th generation UFPA sensor
    Resolution336*256 pixel (640*512 optional)
    Spectral7.5~14μm
    NETD50mK(@25℃ F1.0)
    Focal length25~75mm21~105mm30~120mm31~155mm38~190mm
    FOV(H)13°~4.3°18°~3.4°11°~2.8°11.2°~2.2°9.5°~1.9°
    IFOV0.22~0.68mrad0.17~0.85mrad0.14~0.57mrad0.11~0.55mrad0.09~0.45mrad
    Lens controlMotorized zoom and focus(optional auto focus)
    Image processing1. Stable operational temperature without TEC, starting time less than 4 seconds
    2. SDE digital image processing
    3. 10 pseudo color and B/W, B/W inverse
    4. AGC
    5. 2X digital amplification
    Housing1. Material:High strength aluminum alloy shell,waterproof seal,To avoid the growth of mold and moisture generated
    2. Structure:Integrated single-window design
    3. Surface coating:PTA three-resistance coating, Seawater corrosion resistance
    4. Interface:Aviation waterproof plug
    PT(optional)1. Duty: 20kg
    2. Rotation: Pan: 0~355°, Tilt: -60~+10°
    3. Rotation speed: Pan: 9°/S, Tilt: 4°/S,
    4. Preset 32(Optional variable speed PT)
    Interface
    • RS-485(PELCO D protocol, baud rate 2400bps
    • Remote OSD setting
    3. PAL/NTSC video output
    4. AC24V ( DC12V optional)
    5. Waterproof connector
    Environment
    • Operating temperature:-25℃~+55℃(-40℃ optional)
    • Storage temperature:-35℃~+75℃
    • Humidity:<90%
    • Ingress protection:IP66

    * The detection distance is related to the object and environment etc. Please contact with us for further information.
