    Portable Infrared Cooled Thermal Heat Binoculars With Day Night Surveillance

    Ask Lasest Price
    Brand Name : Hope-Wish
    Model Number : HP-FCT630
    Certification : CE,FCC
    Payment Terms : L/C, T/T, Western Union
    Price : Negotiable
    • Product Details
    • Company Profile

    Portable Infrared Cooled Thermal Heat Binoculars With Day Night Surveillance

    Portable Infrared cooled Thermal Imaging Binocular with Day&Night Surveillance

    HP-FCT Series Handheld Cooled Thermal Camera integrates infrared detector, E-compass, visible camera and eye-safe grade LRF. Featuring continuous zoom and compact design, the camera is ideal for observation on the battle field, and such applications as border and costal defense.
    Features:

    1. Compact design;
    2. Continuous zoom: while tracking, user can zoom in for closer observation of target.
    3. Multi-components, all in one: an IR system combined with GPS, E-compass and LRF provides user precise position, thus ensuring the target is hit with zero error;
    4. Flexible image display: video can be either displayed on color OLED of this camera or viewed on a bigger screen in control center;
    5. Storage: extendable to 16GB
    6. Max storage: 5 hours video/10000 pictures
    7. Digital video compression: 100 megabits Ethernet, video compressed(H.264) to relieve network loads.

    Application:
    Patrol ;Surveillance ;Detection ;Security surveillance ;Military / border / customs security .

    ModelHP-FCT330HP-FCT630HP-FCT3324
    IR detector
    DetectorMid-wave cooled FPA, MCT
    Resolution320×256640×512320×256
    Pixel size30μm15μm30μm
    Spectral response3.7μm ~4.8μm
    Lens
    Focal length30mm~300mm continuous zoom, auto focus.60mm/240mm, bi-FOV
    F#4.0
    FOV18.18°×14.59°~2.29°×1.83°9.15°×7.32°~2.29°×1.83°
    Detection
    Human (1.8m×0.5m)

    Detection: 6.5km
    Recognition: 2.5km

    Detection: 8.6km
    Recognition: 4.2km

    Detection: 6.5km
    Recognition:2.5km

    Tank (2.3m×2.3m)

    Detection: 9.2km
    Recognition: 4.1km

    Detection: 13.4km
    Recognition: 7.2km

    Detection :9.2km
    Recognition: 4.1km

    Visible camera
    Resolution640×512752×582800×600
    Focal length120mm fixed focus3.3mm 120mm50mm
    CCD1/4”1/4”1/4”
    Video format

    Analog video: PAL(25Hz)
    Network video(100M)

    OLED eyepiece0.5 inch high-resolution OLED 800×600
    Digital zoom×1, ×2, ×4
    Image enhancementAuto image filter, DDE, partition loads and blank-off(IR526B is equipped with micro-scanning enhancement function).
    Brightness / contrastAuto / manual
    Color modeHot-white / hot-black, color .
    Storage
    Storage16G SD card
    Picture storage.JPEG format picture7000pcs.JPEG format picture 10000pcs
    Video storageMP4 format video 5hAVI no loss compression video 2.5h
    GPS
    Accuracy±5m
    E-compass
    Resolution0.1°
    Precision0.5(RMS)
    LRF
    Laser wavelength1.57μm, eye-safe level.
    Accuracy±5m
    Measuring distance2.3m×2.3m target, ≥6km5m×5m target, ≥10km2.3m×2.3m target, ≥4Km
    Power supply
    Input power24V adapter or standard lithium battery.
    Battery working time>4h>5h
    Interface
    Electric interfacePower supply, serial port, USB, analog video port, network port
    Mechanical interface1/4 inch spider
    Physical characteristics
    Weight

    5.2kg
    (4.7kg battery excluded)

    5.0kg
    (4.5kg battery excluded)

    3.5kg(battery included )
    Dimension (eyepiece included)368mm×255mm×111mm378mm×247mm×118mm360mm×236mm×118mm
