    10km Surveillance Ultra Long Range Infrared Surveillance Camera With Intruder Alarm

    Ask Lasest Price
    Brand Name : Hope-Wish
    Model Number : TC4412
    Certification : CE,FCC
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    • Product Details
    • Company Profile

    10km Surveillance Ultra Long Range Infrared Surveillance Camera With Intruder Alarm

    10km Surveillance Ultra Long Range Infrared PTZ Thermal Imaging Camera With Intruder alarm


    Feature


    • Non-uniform image correction technology, stable working temperature without TEC, good image uniformity and dynamic range. SDE digital image processing, no image noise, 10 pseudo color image and B/W, B/W inverse.
    • One integral aluminum alloy housing, weatherproof IP 66, waterproof, anti-dust.
    • NETD 50mk enhance the imaging details even in foggy/rainy/snowy weather.
    • Special AS optical zooming lens and 3CAM high-precision optomechanical design suit for both large-scale seeking and long-distance watching.

    Application

    Oilfield safety, railway&freeway security, river&airport security, forest fire prevention, city safety.


    Technical specification


    ModelTC4412A
    DetectionVehicle:10000m
    Human:4000m
    IdentificationVehicle:2800m
    Human:1000m
    Sensor5th generation UFPA sensor
    Resolution336*256 pixel (640*512 optional)
    Spectral7.5 ~ 14μm
    NETD50mK (@25 ℃ F1.0)
    Focal length30 ~ 120mm
    FOV(H)11° ~ 2.8°
    Lens controlMotorized zoom and focus(optional auto focus)
    Lens designAS+DOE Advanced optical design, High infrared transmittance
    Zoom without virtual focus
    Image processingStable operational temperature without TEC, starting time less than 4 seconds
    SDE digital image processing
    10 pseudo color and B/W, B/W inverse
    AGC
    2X digital amplification
    HousingMaterial : High strength aluminum alloy shell , waterproof seal , To avoid the growth of mold and moisture generated
    Interface : Aviation waterproof plug
    PT ( optional )Duty: 20kg
    Rotation: Pan: 0 ~ 355°, Tilt: -60 ~ +10°
    Rotation speed: Pan: 9°/S, Tilt: 4°/S ,
    Preset 32 ( Optional variable speed PT )
    InterfaceRS-485 ( PELCO D protocol, baud rate 2400bps
    Remote OSD setting
    PAL/NTSC video output
    AC24V ( DC12V optional)
    Waterproof connector
    EnvironmentOperating temperature : -25 ℃~ +55 ℃( -40 ℃ optional )
    Storage temperature : -35 ℃~ +75 ℃
    Humidity : <90%
    Anti-lighting : built-in auto Fuse-protected device, Power 4000V , Signal 2000V
    Ingress protection : IP66


    .
