| Model | TTVC6105-1930 | TTVC6307-1930 | TTVC6510-2030 | TTVC6515-2050 | TTVC6515-2075 |
| Detection*(for 2mX2m hot spots) | 2000m | 3000m | 4000m | 6000m | 6000m |
| Sensor | 5th generation MEMS UFPA VOx sensor |
| Resolution | 640*512 |
| Spectral response | 7.5~14μm |
| NETD | 50mK(@25℃F1.0) |
| Focal length | 50mm | 25-75mm, 3X continuous zoom | 21-105mm,5X continuous zoom | 31-155mm,5X continuous zoom | 31-155mm, 5X continuous zoom |
| FOV | 6.5°*4.8° | 13°*9.7°～4.3°*3.2° | 18°*13.5°～3.4°*2.7° | 11.25°*8.5°～2.25°*1.7° | 11.25°*8.5°～2.25°*1.7° |
| IFOV | 0.34mrad | 0.22~0.68mrad | 0.17~0.85mrad | 0.11~0.55mrad | 0.11~0.55mrad |
| Lens control | Motor zoom, focus (optional auto focus) |
| CCD | ü 1/2.8''CMOS; ü 0.01lux low illuminate color to BW; ü 2.1megapixel, auto ICR switch; ü H264/MPEG4/MIPEG video standard, support dual stream; ü Video data rate:32Kbps~16Mbps,60hz,30 frame frequency /s . | 1/1.8'' CMOS ; 0.0002lux star light level super low illuminate color to BW ; 2 mega pixel,1920X1080,integral ICR filter ; H.264/MPEG4/MIPEG video format, support dual stream ; Video data rate :32Kbps~16Mbps,60Hz30 frame/s. ABF auto adjustment. |
| Lens | ü 4.3～129mm ü F1.6~F5.0 ü FOV(H)65°~2.3° ü Mega pixel, motorized variable, 1s auto focus. | ü 12～320mm ü F2.0~360 ü FOV(H)4.1°~1.1° ü M.O.D : 1.5m ü Megapixel HD Infrared correction ü Electric variable DC8~12V, ü auto iris | 15～528mm F3.0～360 FOV(H)23°～0.74° M.O.D. : 4m Wide spectral design Electric variable,DC8-12V,auto iris
| 30～750mm F4.6～360 FOV(H)11°～0.5° M.O.D.:2.5m 105mm aperture ; Electric variable,DC8-12V,auto iris, DC5V accurate preset,zoom /
focusfeedback |
| Image processing | 1. Stable operation temperature without TEC, starting time less
than 4 seconds |
| 2. SDE digital image processing |
| 3. 10 pseudo color and B/W, B/W inverse |
| 4. Brightness, contrast, gamma correction |
| 5. 2X digital amplification |
| 6. Optional penetrate fog function |
| Hot target intelligent alarm | 1. 255 adjustable alarm threshold values |
| 2. Adjustable monitoring area, auto detection of target size |
| 3. 1-16 alarm targets, auto selection of the most obvious one |
| 4. Two types of alarm: screen display and audible alarm |
| 5. Less than 0.01s alarm response ensures no omission |
| 6. All parameters can be modified via OSD menu, universally
adaptable |
| 7. Optional IP network coding transmission, and provide free
platform and SDK |
| Housing | 1. Material: integral aluminum alloy housing, stainless steel, anti
strong wind ; |
| 2. Structure: Integral double window |
| 3. Window glass: 4mm optical glass ,transmission＞98% ； |
| 4. Surface coating: PTA three-proofing coatings , |
| 5. Protection:IP66 sealing rate, anti sea water
corrosion(optional); |
| 6. Applied thermal balance design and wide temperature electronics
,which could operate under high / low temperature ; |
| 7. Interface : waterproof aviation connector ; |
| PT | 1. Load: 30kg | 50kg |
| 2. Rotation: pan: 0～360°, tilt: -75°～+45° | pan: 0～360°, tilt: -45°～+45° |
| 3. Rotation speed: Pan:0.1~60°/s, tilt: 0.1~30°/s | Pan:0.1~30°/s, tilt: 0.1~15°/s |
| 4. 80 preset, 256 can be extended. Intelligent functions such as
cruise, the apple peel scanning |
| 5, windproof, anti-shake |
| 6, automatic locking function, produce the alarm when without
background software command |
| 7, the OSD menu function, location, real-time display |
| 8, can real-time back azimuth information, linkage with GIS map
location |
| Main board | 1. 32 bit ARM embedded MCU control circuit ; |
| 2. DC3V,5V,12V,24V multiple power supply to ensure stable operation
of camera ,detector ,lens and PT ; |
| 3. 5 groups of 12bits AD sampling hole, built-in synchronous
algorithm data ,which could ensure focal length and PT rotation
synchronously follow up with presets ; |
| 4.Reserved video processing interface , could extend lens auto
focus function; |
| 5. Optional: Intelligent 3D positioning function. Control PT
rotation and Lens zoom functions . |
| Interface | 1. RS-422(PELCO D protocol, Baud rate 2400bps), PAL/NTSC, HD
network, switch alarm |
| 2. Optional DVE102 intelligent hybrid encoder, RJ45 network
interface communication (including video and azimuth of return
data, PTZ control, alarm data transmission) |
| 3. AC24V(DC24V optional) |
| 4. Military level waterproof connector |
| Protocols | 1. Support TCP/IP,HTTP,DHCP,DNS,DDNS,RTP protocols ; |
| 2. Support Onvif 2.0 |
| 3. Support Pelco-D Pelco-P, baud rate:2400,4800,9600,19200 optional
; |
| Power supply | AC24V / DC24V ±10 ％,50HZ, AC220V→AC24V adapter . |
| Environment indicator | 1. One integral aluminum alloy housing. IP66 ingress protection |
| 2. Operational temp.: -25°～55° (-40° optional) |
| 3. Storage temp.: -35°～75° |
