    50° Laser Source infrared PTZ Camera With 808nm Illuminator Surveillance

    Ask Lasest Price
    Brand Name : Hope-Wish
    Model Number : BRC1920
    Certification : CE,FCC
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    • Product Details
    • Company Profile

    50° Laser Source infrared PTZ Camera With 808nm Illuminator Surveillance

    300m Night Vision PTZ Laser Camera NIR With 808nm illuminator Surveillance


    BRC19 camera could rotate to the proposed position quickly and accurately. The camera has 128 preset, recording and patrol function and could preset anywhere. It also have automatic exposure, automatic focus function.

    Feature

    • 50°laser source, max illumination distance 300~420m.
    • Unique DSS digital illumination angle control, 0.1°minimum zooming accompany camera.
    • GHT-II super homogenizing ensures a better imaging effect.
    • Independent photos which ensures the synchronization of B&W conversion and laser source turning on.
    • Built-in intelligent delay to avoid the influence of car light.
    • One integral aluminum alloy housing, water proof and dustproof, IP66 ingress protection.

    Application

    Applicable to the field of Police, highways, urban management , Law enforcement vehicles, fire fighting truck,

    Highways, Train and other special vehicle monitoring, Top

    Mounting, it can be used to obtain evidence, emergency rescue, scene investigation,Construction work,

    accident treatment, rescue and emergency illumination such as in the bad lighting conditions environment.


    Technical specification

    ModelBRC1920BRC1930BRC1920XBRC1930X
    DetectionDay: 700Day: 800mDay: 700mDay: 800m
     Night: 300mNight: 300mNight: 420mNight: 420m
    Sensor1/2.8'' B&W Sony CCD, 2.1 MP, 1920X1080, automatic ICR switch
    EncodingVideo compression: H.264, code stream 32k~16Mbps,support dual stream, the heart, smart restructuring, electronic shutter, white balance, 3D DNR, DWDR, automatic exposure, support SD card, motion detection, mask alarm
    Image settingLightness, contrast radio, saturation
    Lens

    4.7~94mm,20 optical zoom

    F1.6~F3.5

    4.3~120mm,30 optical zoom

    F1.6~F5.0

    4.7~94mm,20 optical zoom

    F1.6~F3.5

    4.3~129mm,30 optical zoom

    F1.6~F5.0

    FOV61.4°~2.9°65°~2.3°61.4°~2.9°65°~2.3°
    Min.Illumination0.005lux B/W0.05lux Color/
    Consumption5W,808nm ,NIR
    Laser lens30mm F1.0 Fast lens,GHT-II homogenizing30mmF1.4 telephoto lens,GHT-II homogenizing
    Laser angle2°~50°1.2°~40°
    Angle controlDSS digital illumination control,30ms fast track response, min 0.1° illumination zooming, manual/automatic
    Optical axis aiming0.01°SLM automatic axis automatic aiming and locking ,reserved external interface, maintaining without take out the case
    Pan rotation0°~360° continuously
    Tilt rotation-90°~+90°
    Rotation speedPan: 0°~100°/s,Tilt: 0°~80°/s
    Preset128
    Line scan3 path(User could set up the starting point, destination and scanning speed)
    Patrol6 path(each path have 16 point, staying time is adjustable)
    Customized functionCustomizable privacy shade, 3D box chosen magnification
    InterfaceRJ45,10M/100M adaptive Ethernet,TCP/IP,RTP/RTCP,HTTP
    CompatibilitySupport ONVIF,GB/T28181
    Heat/demisting/ wiperYes
    Laser switchAuto/manual
    Ingress protectionIP66,anti-lighting,anti surge
    Operational temp.-35~55℃
    Power supplyAC24V/2.5A,DC12V/3.5A, common≤40W,peak≤60W
    Weight7kg

    * The detection distance is related to the object and environment etc. Please contact with us for further information.
