    Waterproof Cooled Thermal Camera With 20km Long Range Border Surveillance

    Ask Lasest Price
    Brand Name : Hope-Wish
    Model Number : CTC63570
    Certification : CE,FCC
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    • Product Details
    • Company Profile

    Waterproof Cooled Thermal Camera With 20km Long Range Border Surveillance


    640x512 MWIR Cooled Thermal Camera with 50km Long Range Surveillance


    CTC Series Ultra Long Range Cooled Thermal Camera is developed on the basis of the latest cooled IR technology. Featuring high NETD, advanced digital circuit and image processing algorithm, the camera provides users crisp thermal images. The camera comes in 3 types, i.e. 20X continuous zoom, bi-fov and tri-fov.


    While ensuring wide coverage, it also meets ultra long range surveillance demand with 40km detection range. The camera enclosure is IP66 rated, which is designed to withstand the harshest weather conditions.


    Application

    Costal defense, harbor, oil field, river lane, airport, safe city.


    Technical specification

    ModelCTC61530CTC62245CTC63570CTC610105
    DetectionVehicle:18000mVehicle:19000mVehicle:20000mVehicle:22000m
    Human: 11000mHuman:12000mHuman: 15000mHuman:18000m
    IdentificationVehicle:7000mVehicle:9000mVehicle:15000mVehicle:15000m
    Human:3500mHuman:4500mHuman:6500mHuman:9000m
    DetectorFPA MCT detector
    CoolingStirling cryocooler
    Resolution640×512
    Pixel size15μm X15μm
    Spectral range3.7-4.8μm, NWIR
    NETD20mK(@25 ℃)
    Lens15~300mm, 20X continuous optical zoom F4.022~450mm continuous zoom F4.035~700mm continuous zoom F4.0105~1050mm continuous zoom F4.0
    FOV35°×28°~1.8°×1.4°25°×18° ~1.3°×1°16°×12° ~0.8°×0.6°5°×4°~0.5°×0.4°
    Lens controlManual/auto focus
    Image processingImage enhancement: SDE;
    Color: White hot/Black hot;
    Brightness and contrast: AGC, adjustable;
    Digital zoom: 2X, 4X
    Cross: display
    Correction: Shutter/Background
    InterfaceControl: RS485/RS232(PELCO D, baud rate:2400bps/s)
    Menu: OSD
    Video: PAL
    Power supply: DC24V
    Connector: waterproof aviation connector
    Environmental indicatorsEnclosure: aluminum alloy, sealed;
    Working temp: -40°-55°
    Storage temp: -40°-70°
    Ingress protection: IP67
    Power consumption: 15W(normal), 45W(peak)
    DimensionWeight: 5kgWeight: 6.5kgWeight: 9.5kgWeight: 10kg
    DimensionDimensionDimensionDimension

    250mm×120mm

    ×100mm

    330mm×132mm

    ×150mm

    390mm×210mm

    ×210mm

    420mm×230mm

    ×210mm

    * The detection distance is related to the object and environment etc. Please contact with us for further information
