| Model | BRC1920 | BRC1930 |
| Detection | Day: 700 | Day: 800m |
| | Night: 300m | Night: 300m |
| Sensor | 1/2.8'' B&W Sony CCD, 2.1 MP, 1920X1080, automatic ICR switch |
| Encoding | Video compression: H.264, code stream 32k～16Mbps,support dual
stream, the heart, smart restructuring, electronic shutter, white
balance, 3D DNR, DWDR, automatic exposure, support SD card, motion
detection, mask alarm |
| Image setting | Lightness, contrast radio, saturation |
| Lens | 4.7～94mm,20 optical zoom F1.6～F3.5 | 4.3～120mm,30 optical zoom F1.6～F5.0 |
| FOV | 61.4°～2.9° | 65°～2.3° |
| Min.Illumination | 0.005lux B/W0.05lux Color/ |
| Consumption | 5W,808nm ,NIR |
| Laser lens | 30mm F1.0 Fast lens,GHT-II homogenizing |
| Laser angle | 2°～50° |
| Angle control | DSS digital illumination control,30ms fast track response, min 0.1°
illumination zooming, manual/automatic |
| Optical axis aiming | 0.01°SLM automatic axis automatic aiming and locking ,reserved
external interface, maintaining without take out the case |
| Pan rotation | 0°~360° continuously |
| Tilt rotation | -90°~+90° |
| Rotation speed | Pan: 0°~100°/s,Tilt: 0°~80°/s |
| Preset | 128 |
| Line scan | 3 path(User could set up the starting point, destination and
scanning speed) |
| Patrol | 6 path(each path have 16 point, staying time is adjustable) |
| Customized function | Customizable privacy shade, 3D box chosen magnification |
| Interface | RJ45,10M/100M adaptive Ethernet,TCP/IP,RTP/RTCP,HTTP |
| Compatibility | Support ONVIF,GB/T28181 |
| Heat/demisting/ wiper | Yes |
| Laser switch | Auto/manual |
| Ingress protection | IP66,anti-lighting,anti surge |
| Operational temp. | -35~55℃ |
| Power supply | AC24V/2.5A,DC12V/3.5A, common≤40W,peak≤60W |
| Weight | 7kg |
